View Chapter

Chapter 36 — Motion for Manipulation Tasks

James Kuffner and Jing Xiao

This chapter serves as an introduction to Part D by giving an overview of motion generation and control strategies in the context of robotic manipulation tasks. Automatic control ranging from the abstract, high-level task specification down to fine-grained feedback at the task interface are considered. Some of the important issues include modeling of the interfaces between the robot and the environment at the different time scales of motion and incorporating sensing and feedback. Manipulation planning is introduced as an extension to the basic motion planning problem, which can be modeled as a hybrid system of continuous configuration spaces arising from the act of grasping and moving parts in the environment. The important example of assembly motion is discussed through the analysis of contact states and compliant motion control. Finally, methods aimed at integrating global planning with state feedback control are summarized.

Control pre-imaging for multifingered grasp synthesis

Author  Jefferson A. Coelho Jr. et al.

Video ID : 363

The video demonstrates sensory-motor control for multifingered manipulation. The first part of the video shows a top and a lateral grasp of rectangular blocks synthesized by the proposed controller. The second part shows dexterous manipulation tests, controlling stable multiple fingers to walk over the surface of an object while grasping the object.

Chapter 40 — Mobility and Manipulation

Oliver Brock, Jaeheung Park and Marc Toussaint

Mobile manipulation requires the integration of methodologies from all aspects of robotics. Instead of tackling each aspect in isolation,mobilemanipulation research exploits their interdependence to solve challenging problems. As a result, novel views of long-standing problems emerge. In this chapter, we present these emerging views in the areas of grasping, control, motion generation, learning, and perception. All of these areas must address the shared challenges of high-dimensionality, uncertainty, and task variability. The section on grasping and manipulation describes a trend towards actively leveraging contact and physical and dynamic interactions between hand, object, and environment. Research in control addresses the challenges of appropriately coupling mobility and manipulation. The field of motion generation increasingly blurs the boundaries between control and planning, leading to task-consistent motion in high-dimensional configuration spaces, even in dynamic and partially unknown environments. A key challenge of learning formobilemanipulation consists of identifying the appropriate priors, and we survey recent learning approaches to perception, grasping, motion, and manipulation. Finally, a discussion of promising methods in perception shows how concepts and methods from navigation and active perception are applied.

Handling of a single object by multiple mobile robots based on caster-like dynamics

Author  Kazuhiro Kosuge

Video ID : 785

When multiple robots are utilized for the handling of an object, the slippage between wheels and the ground is the most serious challenge for coordinating the multiple robots. A control algorithm has been developed for mobile robots, which assumes they each possess caster-like dynamics.

Chapter 4 — Mechanism and Actuation

Victor Scheinman, J. Michael McCarthy and Jae-Bok Song

This chapter focuses on the principles that guide the design and construction of robotic systems. The kinematics equations and Jacobian of the robot characterize its range of motion and mechanical advantage, and guide the selection of its size and joint arrangement. The tasks a robot is to perform and the associated precision of its movement determine detailed features such as mechanical structure, transmission, and actuator selection. Here we discuss in detail both the mathematical tools and practical considerations that guide the design of mechanisms and actuation for a robot system.

The following sections (Sect. 4.1) discuss characteristics of the mechanisms and actuation that affect the performance of a robot. Sections 4.2–4.6 discuss the basic features of a robot manipulator and their relationship to the mathematical model that is used to characterize its performance. Sections 4.7 and 4.8 focus on the details of the structure and actuation of the robot and how they combine to yield various types of robots. The final Sect. 4.9 relates these design features to various performance metrics.

Robotic milking system

Author  Lena Rosenbohm

Video ID : 643

Fig. 4.12 DeLaval Cow Milking System features a hydraulic robot with machine-vision guided positioning.

Chapter 17 — Limbed Systems

Shuuji Kajita and Christian Ott

A limbed system is a mobile robot with a body, legs and arms. First, its general design process is discussed in Sect. 17.1. Then we consider issues of conceptual design and observe designs of various existing robots in Sect. 17.2. As an example in detail, the design of a humanoid robot HRP-4C is shown in Sect. 17.3. To design a limbed system of good performance, it is important to take into account of actuation and control, like gravity compensation, limit cycle dynamics, template models, and backdrivable actuation. These are discussed in Sect. 17.4.

In Sect. 17.5, we overview divergence of limbed systems. We see odd legged walkers, leg–wheel hybrid robots, leg–arm hybrid robots, tethered walking robots, and wall-climbing robots. To compare limbed systems of different configurations,we can use performance indices such as the gait sensitivity norm, the Froude number, and the specific resistance, etc., which are introduced in Sect. 17.6.

Intuitive control of a planar bipedal walking robot

Author  Jerry Pratt

Video ID : 529

The planar bipedal walking robot `Spring Flamingo' driven by series elastic actuators developed by Dr. Jerry Pratt and Prof. Gill Pratt.

Chapter 51 — Modeling and Control of Underwater Robots

Gianluca Antonelli, Thor I. Fossen and Dana R. Yoerger

This chapter deals with modeling and control of underwater robots. First, a brief introduction showing the constantly expanding role of marine robotics in oceanic engineering is given; this section also contains some historical backgrounds. Most of the following sections strongly overlap with the corresponding chapters presented in this handbook; hence, to avoid useless repetitions, only those aspects peculiar to the underwater environment are discussed, assuming that the reader is already familiar with concepts such as fault detection systems when discussing the corresponding underwater implementation. Themodeling section is presented by focusing on a coefficient-based approach capturing the most relevant underwater dynamic effects. Two sections dealing with the description of the sensor and the actuating systems are then given. Autonomous underwater vehicles require the implementation of mission control system as well as guidance and control algorithms. Underwater localization is also discussed. Underwater manipulation is then briefly approached. Fault detection and fault tolerance, together with the coordination control of multiple underwater vehicles, conclude the theoretical part of the chapter. Two final sections, reporting some successful applications and discussing future perspectives, conclude the chapter. The reader is referred to Chap. 25 for the design issues.

Multi-vehicle bathymetry mission

Author  Laboratario de Sistemas e Tecnologias Subaquaticas - Porto University / The NOPTILUS project

Video ID : 323

Two LAUV vehicles perform a bathymetry mission inside Porto Harbor. This video shows the deployment, execution, and data-revision phases of the mission. NOPTILUS is funded by the European Community's Seventh Framework Programme ICT-FP.

Chapter 40 — Mobility and Manipulation

Oliver Brock, Jaeheung Park and Marc Toussaint

Mobile manipulation requires the integration of methodologies from all aspects of robotics. Instead of tackling each aspect in isolation,mobilemanipulation research exploits their interdependence to solve challenging problems. As a result, novel views of long-standing problems emerge. In this chapter, we present these emerging views in the areas of grasping, control, motion generation, learning, and perception. All of these areas must address the shared challenges of high-dimensionality, uncertainty, and task variability. The section on grasping and manipulation describes a trend towards actively leveraging contact and physical and dynamic interactions between hand, object, and environment. Research in control addresses the challenges of appropriately coupling mobility and manipulation. The field of motion generation increasingly blurs the boundaries between control and planning, leading to task-consistent motion in high-dimensional configuration spaces, even in dynamic and partially unknown environments. A key challenge of learning formobilemanipulation consists of identifying the appropriate priors, and we survey recent learning approaches to perception, grasping, motion, and manipulation. Finally, a discussion of promising methods in perception shows how concepts and methods from navigation and active perception are applied.

Extracting kinematic background knowledge from interactions using task-sensitive, relational learning

Author  Sebastian Hofer, Tobias Lang, Oliver Brock

Video ID : 671

To successfully manipulate novel objects, robots must first acquire information about the objects' kinematic structure. We present a method to learn relational, kinematic, background knowledge from exploratory interactions with the world. As the robot gathers experience, this background knowledge enables the acquisition of kinematic world models with increasing efficiency. Learning such background knowledge, however, proves difficult, especially in complex, feature-rich domains. We present a novel, task-sensitive, relational-rule learner and demonstrate that it is able to learn accurate kinematic background knowledge in domains where other approaches fail. The resulting background knowledge is more compact and generalizes better than that obtained with existing approaches.

Chapter 58 — Robotics in Hazardous Applications

James Trevelyan, William R. Hamel and Sung-Chul Kang

Robotics researchers have worked hard to realize a long-awaited vision: machines that can eliminate the need for people to work in hazardous environments. Chapter 60 is framed by the vision of disaster response: search and rescue robots carrying people from burning buildings or tunneling through collapsed rock falls to reach trapped miners. In this chapter we review tangible progress towards robots that perform routine work in places too dangerous for humans. Researchers still have many challenges ahead of them but there has been remarkable progress in some areas. Hazardous environments present special challenges for the accomplishment of desired tasks depending on the nature and magnitude of the hazards. Hazards may be present in the form of radiation, toxic contamination, falling objects or potential explosions. Technology that specialized engineering companies can develop and sell without active help from researchers marks the frontier of commercial feasibility. Just inside this border lie teleoperated robots for explosive ordnance disposal (EOD) and for underwater engineering work. Even with the typical tenfold disadvantage in manipulation performance imposed by the limits of today’s telepresence and teleoperation technology, in terms of human dexterity and speed, robots often can offer a more cost-effective solution. However, most routine applications in hazardous environments still lie far beyond the feasibility frontier. Fire fighting, remediating nuclear contamination, reactor decommissioning, tunneling, underwater engineering, underground mining and clearance of landmines and unexploded ordnance still present many unsolved problems.

Bozena 5 remotely-operated robot vehicle

Author  James P. Trevelyan

Video ID : 574

This is an example of several videos available on YouTube showing this Slovak-designed and -constructed machine. It shows the vehicle being used in different test areas with brief glimpses of other mine-resistant vehicles. BOZENA 5 was designed to support mine-clearance teams operating in Croatia, Serbia and Bosnia Herzegovina, removing mines left over from the civil war in the 1990s. In the areas affected by mines, one of the biggest challenges is the rapid growth of vegetation during the summer months. Bare ground can be submerged in vegetation over 1 m high after just two or three weeks. Military defensive positions were often set up on uneven ground with steep slopes which were then mined to deter attacks from other parties in the conflict. Mines were also removed from these defensive minefields and re-laid along routes used for smuggling goods and people. The smugglers would be able to charge higher prices because only they knew how to safely move along the routes. The smuggling routes (and their parent organizations) persisted long after the end of the formal conflict, complicating mine-clearance operations. That is why small, remote control vehicles like this proved to be so effective. They were highly manoeuvrable, easily transported, adaptable with different tools and equipment, and could be safely operated. The machine comes with an armored operator cabin and the whole system can be packed and deployed from a 40-foot shipping container weighing 16 tons. The greatest threat to the de-miners was from bounding fragmentation mines which typically had a lethal radius of several hundred meters. These vehicles provided a means to operate safely in areas affected by these mines. One of the major disadvantages of these machines is the destruction of surface vegetation that can lead to rapid erosion, if there is heavy rain in the weeks following mine clearance operations. Sudden heavy downpours are common in summer months. Therefore, they had to be used with considerable discretion and local knowledge.

Chapter 13 — Behavior-Based Systems

François Michaud and Monica Nicolescu

Nature is filled with examples of autonomous creatures capable of dealing with the diversity, unpredictability, and rapidly changing conditions of the real world. Such creatures must make decisions and take actions based on incomplete perception, time constraints, limited knowledge about the world, cognition, reasoning and physical capabilities, in uncontrolled conditions and with very limited cues about the intent of others. Consequently, one way of evaluating intelligence is based on the creature’s ability to make the most of what it has available to handle the complexities of the real world. The main objective of this chapter is to explain behavior-based systems and their use in autonomous control problems and applications. The chapter is organized as follows. Section 13.1 overviews robot control, introducing behavior-based systems in relation to other established approaches to robot control. Section 13.2 follows by outlining the basic principles of behavior-based systems that make them distinct from other types of robot control architectures. The concept of basis behaviors, the means of modularizing behavior-based systems, is presented in Sect. 13.3. Section 13.4 describes how behaviors are used as building blocks for creating representations for use by behavior-based systems, enabling the robot to reason about the world and about itself in that world. Section 13.5 presents several different classes of learning methods for behavior-based systems, validated on single-robot and multirobot systems. Section 13.6 provides an overview of various robotics problems and application domains that have successfully been addressed or are currently being studied with behavior-based control. Finally, Sect. 13.7 concludes the chapter.

Experience-based learning of high-level task representations: Demonstration

Author  Monica Nicolescu

Video ID : 27

This is a video recorded in early 2000s, showing a Pioneer robot learning to visit a number of targets in a certain order - the human demonstration stage. The robot execution stage is also shown in a related video in this chapter. References: 1. M. Nicolescu, M.J. Mataric: Experience-based learning of task representations from human-robot interaction, Proc. IEEE Int. Symp. Comput. Intell. Robot. Autom. Banff (2001), pp. 463-468; 2. M. Nicolescu, M.J. Mataric: Learning and interacting in human-robot domains, IEEE Trans. Syst. Man Cybernet. A31(5), 419-430 (2001)

Chapter 56 — Robotics in Agriculture and Forestry

Marcel Bergerman, John Billingsley, John Reid and Eldert van Henten

Robotics for agriculture and forestry (A&F) represents the ultimate application of one of our society’s latest and most advanced innovations to its most ancient and important industries. Over the course of history, mechanization and automation increased crop output several orders of magnitude, enabling a geometric growth in population and an increase in quality of life across the globe. Rapid population growth and rising incomes in developing countries, however, require ever larger amounts of A&F output. This chapter addresses robotics for A&F in the form of case studies where robotics is being successfully applied to solve well-identified problems. With respect to plant crops, the focus is on the in-field or in-farm tasks necessary to guarantee a quality crop and, generally speaking, end at harvest time. In the livestock domain, the focus is on breeding and nurturing, exploiting, harvesting, and slaughtering and processing. The chapter is organized in four main sections. The first one explains the scope, in particular, what aspects of robotics for A&F are dealt with in the chapter. The second one discusses the challenges and opportunities associated with the application of robotics to A&F. The third section is the core of the chapter, presenting twenty case studies that showcase (mostly) mature applications of robotics in various agricultural and forestry domains. The case studies are not meant to be comprehensive but instead to give the reader a general overview of how robotics has been applied to A&F in the last 10 years. The fourth section concludes the chapter with a discussion on specific improvements to current technology and paths to commercialization.

A robot for harvesting sweet peppers in greenhouses

Author  Jochen Hemming, Wouter Bac, Bart van Tuijl, Ruud Barth, Eldert van Henten, Jan Bontsema, Erik Pekkeriet

Video ID : 304

This video shows robotic harvesting of sweet-pepper fruits in a commercial Dutch greenhouse in June 2014. The base of the robot consists of two carrier modules. On the first are located the manipulator (nine degrees-of-freedom), specifically developed for this project, the control electronics and the computers. On the sensor carrier module, two 5 megapixel color cameras (comprising a small baseline stereo setup) and a time-of-flight (TOF) camera are installed. Around the sensors, a light grid is placed to illuminate the scene. The sensor system is mounted on a linear motorized slide and can be horizontally moved in and out of the workspace of the manipulator. Machine-vision software localizes ripe fruits and obstacles in 3D. Two different types of end-effectors were designed and tested. The fin-ray gripper features a combined grip and cut mechanism. This end-effector first grips the fruit and after that the peduncle of the fruit is cut. The lip-type end-effector first stabilizes the fruit using a suction cup after which two rings enclose the fruit and cut the peduncle of the fruit. Both end-effectors have a miniature RGB and a TOF camera for refining the fruit position and to determine the fruit pose. This robot demonstrator is one of the results of the EU project CROPS, Clever Robots for Crops (www.crops-robots.eu).

Chapter 67 — Humanoids

Paul Fitzpatrick, Kensuke Harada, Charles C. Kemp, Yoshio Matsumoto, Kazuhito Yokoi and Eiichi Yoshida

Humanoid robots selectively immitate aspects of human form and behavior. Humanoids come in a variety of shapes and sizes, from complete human-size legged robots to isolated robotic heads with human-like sensing and expression. This chapter highlights significant humanoid platforms and achievements, and discusses some of the underlying goals behind this area of robotics. Humanoids tend to require the integration ofmany of the methods covered in detail within other chapters of this handbook, so this chapter focuses on distinctive aspects of humanoid robotics with liberal cross-referencing.

This chapter examines what motivates researchers to pursue humanoid robotics, and provides a taste of the evolution of this field over time. It summarizes work on legged humanoid locomotion, whole-body activities, and approaches to human–robot communication. It concludes with a brief discussion of factors that may influence the future of humanoid robots.

Footstep planning modeled as a whole-body, inverse-kinematic problem

Author  Eiichi Yoshida

Video ID : 596

An augmented-robot structure was introduced as "virtual" planar links attached to a foot that represents footsteps. This modeling makes it possible to solve the footstep planning as a problem of inverse kinematics, and also to determine the final whole-body configuration. After planning the footsteps, the dynamically-stable, whole-body motion including walking can be computed by using a dynamic pattern generator.
